Circle Packing

Circle packing visualizes whole-part and parent-child relationships by packing circles inside other circles. It is a hierarchical visualization technique: each node is drawn as a circle, and parent nodes contain their children.

Compared with a treemap, which divides rectangular space, circle packing is less precise for area comparison but often more intuitive for showing containment and hierarchy depth.

Background

The mathematical idea of packing circles is old and has been studied as the circle packing problem since the nineteenth century. In information visualization, circle packing became widely used in the late 1990s and 2000s, especially through tools such as Protovis and D3.js. D3 provides a standard implementation as d3.pack().

Data Structure

Circle packing uses hierarchical data.

Field	Meaning
name	Node label
value	Numeric size for the node
children	Child nodes

Example:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
{
  "name": "root",
  "children": [
    {"name": "A", "value": 10},
    {"name": "B", "children": [
      {"name": "B1", "value": 5},
      {"name": "B2", "value": 8}
    ]}
  ]
}

Purpose

The main purpose is to show which elements belong to which groups, and roughly how large each group or leaf node is. It is visually softer than a treemap and often works well when structural hierarchy matters more than exact numeric comparison.

Use Cases

file-system structure
biological taxonomy
corporate or industry hierarchy
regional population composition
topic clusters and nested categories

How to Read It

Element	Meaning
Circle size	Relative value or magnitude
Parent and child circles	Hierarchical containment
Color	Category, group, or level
Position	Layout optimized for readability; not usually a measured axis

Design Notes

Area comparison with circles is difficult, so labels and tooltips help.
Deep hierarchies often need interactive zooming.
Use color consistently by level or parent group.
Leave enough padding between circles so boundaries remain legible.

Alternatives

Method	Feature	Best when
Treemap	Rectangular area optimization	Accurate area comparison matters
Sunburst chart	Radial hierarchy	Hierarchy depth matters
Icicle chart	Stacked hierarchy	Labels need more room

Summary

Circle packing is a visually compelling way to show hierarchical structure. It is not the strongest option for exact value comparison, but it is effective when the goal is to reveal the shape of an information hierarchy.
